排量 | 最大壓力 | 最高轉速 | 最低轉速 | 尺寸 | 油口代碼 | 進油口 | 出油口 | 油口代碼 | 進油口 | 出油口 | |||
PA | PB | PA | PB | LA | LB | PA | D | d | PB | D | d | ||
(cm3/rev.) | (cm3/rev.) | bar | bar | (r/min) | (r/min) | mm | mm | ||||||
6 | 6 | 250 | 250 | 2300 | 500 | 56.6 | 56.6 | L0 | G3/4 | G1/2 | L0 | G3/4 | G1/2 |
8 | 8 | 250 | 250 | 58.6 | 58.6 | L0 | G3/4 | G1/2 | L0 | G3/4 | G1/2 | ||
10 | 10 | 250 | 250 | 60.6 | 60.6 | L0 | G3/4 | G1/2 | L0 | G3/4 | G1/2 | ||
12 | 12 | 250 | 250 | 63.1 | 63.1 | L0 | G3/4 | G1/2 | L0 | G3/4 | G1/2 | ||
14 | 14 | 250 | 250 | 64.6 | 64.6 | L0 | G3/4 | G1/2 | L0 | G3/4 | G1/2 | ||
16 | 16 | 250 | 250 | 67.1 | 67.1 | L0 | G3/4 | G1/2 | L0 | G3/4 | G1/2 | ||
19 | 19 | 250 | 250 | 70.6 | 70.6 | L0 | G3/4 | G1/2 | L0 | G3/4 | G1/2 | ||
22 | 22 | 250 | 250 | 74.1 | 74.1 | L0 | G3/4 | G1/2 | L0 | G3/4 | G1/2 | ||
25 | 25 | 250 | 250 | 76.6 | 76.6 | L1 | G1 | G3/4 | L1 | G1 | G3/4 | ||
28 | 28 | 250 | 250 | 79.6 | 79.6 | L1 | G1 | G3/4 | L1 | G1 | G3/4 | ||
30 | 30 | 230 | 230 | 82.1 | 82.1 | L1 | G1 | G3/4 | L1 | G1 | G3/4 | ||
32 | 32 | 230 | 230 | 84.6 | 84.6 | L1 | G1 | G3/4 | L1 | G1 | G3/4 | ||
36 | 36 | 200 | 200 | 88.6 | 88.6 | L1 | G1 | G3/4 | L1 | G1 | G3/4 | ||
38 | 38 | 200 | 200 | 90.6 | 90.6 | L1 | G1 | G3/4 | L1 | G1 | G3/4 | ||
40 | 40 | 170 | 170 | 92.6 | 92.6 | L1 | G1 | G3/4 | L1 | G1 | G3/4 | ||
44 | 44 | 170 | 170 | 97.1 | 97.1 | L1 | G1 | G3/4 | L1 | G1 | G3/4 |
