排量 | 最大壓力 | 最高轉速 | 最低轉速 | 尺寸 | 油口代碼 | 進油口 | 出油口 | 油口代碼 | 進油口 | 出油口 | ||||||||
PA | PB | PA | PB | LA | LB | PA | D | d | PB | D | d | |||||||
(cm3/rev.) | (cm3/rev.) | bar | bar | (r/min) | (r/min) | mm | mm | |||||||||||
1.4 | 1.4 | 250 | 250 | 2500 | 600 | 44.1 | 44.1 | L0 | G1/2 | G3/8 | L0 | G1/2 | G3/8 | |||||
2.1 | 2.1 | 250 | 250 | 46.1 | 46.1 | L0 | G1/2 | G3/8 | L0 | G1/2 | G3/8 | |||||||
2.8 | 2.8 | 250 | 250 | 48.1 | 48.1 | L0 | G1/2 | G3/8 | L0 | G1/2 | G3/8 | |||||||
3.5 | 3.5 | 250 | 250 | 50.1 | 50.1 | L0 | G1/2 | G3/8 | L0 | G1/2 | G3/8 | |||||||
4.1 | 4.1 | 250 | 250 | 52.1 | 52.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 | |||||||
5.2 | 5.2 | 230 | 230 | 55.1 | 55.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 | |||||||
6.2 | 6.2 | 230 | 230 | 58.1 | 58.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 | |||||||
7.6 | 7.6 | 200 | 200 | 62.1 | 62.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 | |||||||
9.3 | 9.3 | 180 | 180 | 67.1 | 67.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 | |||||||
11.0 | 11.0 | 170 | 170 | 72.1 | 72.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 | |||||||
13.8 | 13.8 | 150 | 150 | 80.1 | 80.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 |
排量 | 最大壓力 | 最高轉速 | 最低轉速 | 尺寸 | 油口代碼 | 進油口 | 出油口 | 油口代碼 | 進油口 | 出油口 | |||
PA | PB | PA | PB | LA | LB | PA | D | d | PB | D | d | ||
(cm3/rev.) | (cm3/rev.) | bar | bar | (r/min) | (r/min) | mm | mm | ||||||
1.4 | 1.4 | 250 | 250 | 2500 | 600 | 44.1 | 44.1 | L0 | G1/2 | G3/8 | L0 | G1/2 | G3/8 |
2.1 | 2.1 | 250 | 250 | 46.1 | 46.1 | L0 | G1/2 | G3/8 | L0 | G1/2 | G3/8 | ||
2.8 | 2.8 | 250 | 250 | 48.1 | 48.1 | L0 | G1/2 | G3/8 | L0 | G1/2 | G3/8 | ||
3.5 | 3.5 | 250 | 250 | 50.1 | 50.1 | L0 | G1/2 | G3/8 | L0 | G1/2 | G3/8 | ||
4.1 | 4.1 | 250 | 250 | 52.1 | 52.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 | ||
5.2 | 5.2 | 230 | 230 | 55.1 | 55.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 | ||
6.2 | 6.2 | 230 | 230 | 58.1 | 58.1 | L1 | G1/2 | G1/2 | L1 | Feb-61 | G1/2 | ||
7.6 | 7.6 | 200 | 200 | 62.1 | 62.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 | ||
9.3 | 9.3 | 180 | 180 | 67.1 | 67.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 | ||
11 | 11 | 170 | 170 | 72.1 | 72.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 | ||
13.8 | 13.8 | 150 | 150 | 80.1 | 80.1 | L1 | G1/2 | G1/2 | L1 | G1/2 | G1/2 |
我們的技術銷售團隊擁有廣泛的關于泵的知識和豐富的應用經驗。今天就與我們聯系尋求幫助和支持吧!
